How does the anti-metal RFID tag achieve "no interference"

The anti-metal RFID tag is an electronic label encapsulated with a special anti-magnetic absorbing material.

Many RFID tags need to be attached to the surface of a metal object. When a conventional passive UHF RFID tag with a dipole antenna is applied to a metal surface, the performance is drastically reduced and can not even be read effectively.

Metal objects' influence on the label antenna parameters and performance mainly come into two aspects: one is the antenna field, another is the antenna parameters (such as: impedance, S parameters, radiation efficiency).

In the field where the antenna is operated, there are the incident wave emitted by the reader and the reflected wave reflected by the metal plate, and the incident wave and the reflected wave have a certain phase difference, resulting in a certain degree of mutual cancellation between the two. In this way, the tagged antenna operating in this
environment can not sense enough current to provide energy to the tag chip, making the tag chip can not be activated to cause it fail.

And the antenna parameter changes because the antenna works on the metal surface, the metal plate as part of the antenna itself, so that even if the physical size of the antenna does not change, its impedance value, S parameters, etc. have changed, resulting in the antenna Performance degradation.

Therefore, the appropriate anti-metal label, is a prerequisite to ensure RFID system application.
So, what can solve the RFID anti-metal label interference?

1, absorbing material
Nowadays, the most common method is to paste a layer of magnetically absorbing material behind the RFID tag. The permeability of the absorbing material is usually higher than that of the metallic material, so as to change the magnetic field of the RFID tag, and adjust the label and the reader to a same frequency, it can make RFID tags to work normal.

2, producing label mold
Pad the distance between the label and the metal, with a certain distance, the impact of electromagnetic waves on the label will be relatively reduced.

3, ceramic rfid tag
Ceramic molecular gap is relatively large, will not be affected by electromagnetic interference and affect, will improve the efficiency of RFID tags reading.

Want to know more about anti-metal labels, welcome to contact us:
OPP IOT Technologies CO., LTD.
Address:2104 Room SANDI International Finance Centre,249# MingXin Street
LongQiao,ChengXiang Putian City Fujian, P.R, China
P.C: 351100
Tel: (0086)594 2790031
Fax: (0086)594 2790185
E-mail:info@oppiot.com ; oppiotrfid@gmail.com
WhatsApp: +86 180 3034 2267

Friday, October 27, 2017

Metal-mount RFID tags OPP0803


OPP IOT offer metal-mount RFID tags OPP0803 that are specifically developed to perform optimally when attached to metal objects. You can use them to track computers and IT assets, tools, machinery, returnable containers and other metal items.
More view http://www.oppiot.com/uhf-metal-tags-atom-series-opp0803.html

Sunday, October 22, 2017

UHF RFID Small size on Metal PCB Tag Diameter 6mm OPPD6 for asset tracking


UHF RFID Small size on Metal PCB Tag OPPD6 is designed on FR-4 base material. It solves the problem that tags can not be attached to metal surface(Reading distance even will be father when it is attached to metal surface). At the same time. it can work outside in the hard environment. It complaints with EPC C1G2 (ISO18000-6C). operating frequency is 860-960MHz (It can be used worldwide).

Functional Specifications:
RFID Protocol:EPC Class1 Gen2, ISO18000-6C
Frequency:US 902-928MHz, EU 865-868MHz
IC type Alien Higgs-3
Memory:EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Write Cycles:100,000times
Functionality:Read/write
Data Retention:Up to 50 Years
Applicable Surface:Metal Surfaces
Read Range (On Metal):
(Fix Reader:ThingMagic M6-E, 36dBm/4W) 85cm - (US) 902-928MHz, on metal
75cm - (EU) 865-868MHz, on metal
Read Range(On Metal):
(Handheld Reader: OP9908,R2000,33dBm/2W)
45cm - (US) 902-928MHz, on metal
45cm - (EU) 865-868MHz, on metal
Warranty:1 Year

Physical Specification:
Size:Diameter6mm, (Hole: D2mmx1)
Thickness:4.0mm with IC bump
Material:FR4 (PCB)
Colour:Black (Red, Blue, Green, White)
Weight:0.5g

Enivironmenal Specification:
IP Rating:IP68
Storage Temperature:-40°C to +150°C
Operation Temberture:-40°C to +100°C
Certifications:Reach Approved,RoHS Approved,CE Approved

More view http://www.oppiot.com/uhf-metal-tags-atom-series-oppd6.html

High Temperature Resisted UHF RFID on Metal Tag OPPD16



UHF PCB On metal Passive RFID tags OPPD16 are designed and produced by special technology and process, for indoor and outdoor usage in harsh industrial environment like metal, acidic, alkaline, wet, etc. It is easy to apply it on metal surface and has excellent performance of being read and written in long distance. We imported original chips of famous brands such as Impinj, Alien, NXP, etc. which is with 860-960Mhz and compliant with EPC Class 1 Gen 2, ISO18000-6C/6B standard.
OPPD16 Typical Applications
Tools Tracking, Oil & Gas, Healthcare Assets, Industrial manufacturing management, IT & Enterprise Asset Management, Warehouse management, Car component management, Metal Shipping Container management, Asset and instrument management, Guns management, Exist and entrance management etc.
Functional Specifications:
RFID Protocol:EPC Class1 Gen2, ISO18000-6C
Frequency:US 902-928MHz, EU 865-868MHz
IC type:Alien Higgs-3
Memory:EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Write Cycles:100,000times
Functionality:Read/write
Data Retention:Up to 50 Years
Applicable Surface:Metal Surfaces
Read Range(On Metal):
(Fix Reader:ThingMagic M6-E, 36dBm/4W) 260cm – (US) 902-928MHz, on metal
240cm – (EU) 865-868MHz, on metal
Read Range(On Metal):
(Handheld Reader: OP9908,R2000,33dBm/2W)
160cm – (US) 902-928MHz, on metal
150cm – (EU) 865-868MHz, on metal
Warranty:1 Year
Physical Specification:
Size:diameter 16mmxT3.0mm (Hole:D2mm*2)
Thickness:3.0mm
Material:FR4 (PCB)
Colour:Black (Red, Blue, Green, White)
Mounting Methods:Adhesive, Screw
Weight:1.3g
Enivironmenal Specification:
IP Rating:IP68
Storage Temperature:-40°C to +150°C
Operation Temberture:-40°C to +100°C
Certifications:Reach Approved,RoHS Approved,CE Approved

EPC global C1G2/ISO 180000-6C UHF rfid anti-metal tag OPPD13


UHF Metal Mount Tag OPPD13 is a durable EPC Class1 Gen2 UHF on metal tag developed for demanding industrial applications.The tag is fully encapsulatedand designed to fit onto metallic surfaces either mechanically or with industrial adhesive.Challenging on metal identification applications can be realised using UHF Metal Mount Tag OPPD13.
Functional Specifications:
RFID Protocol:EPC Class1 Gen2, ISO18000-6C
Frequency:US 902-928MHz, EU 865-868MHz
IC type:Alien Higgs-3
Memory:EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Write Cycles:100,000times
Functionality:Read/write
Data Retention:Up to 50 Years
Applicable Surface:Metal Surfaces
Read Range(On Metal):
(Fix Reader:ThingMagic M6-E, 36dBm/4W) 150cm – (US) 902-928MHz, on metal
130cm – (EU) 865-868MHz, on metal
Read Range(On Metal):
(Handheld Reader: OP9908,R2000,33dBm/2W)
110cm – (US) 902-928MHz, on metal
90cm – (EU) 865-868MHz, on metal
Warranty:1 Year
Physical Specification:
Size:diameter 10mmxT3.0mm (Hole:D2mm)
Thickness:2.0mm
Material:FR4 (PCB)
Colour:Black (Red, Blue, Green, White)
Mounting Methods:Adhesive, Screw
Weight:0.7g
Enivironmenal Specification:
IP Rating:IP68
Storage Temperature:-40°C to +150°C
Operation Temberture:-40°C to +100°C
Certifications:Reach Approved,RoHS Approved,CE Approved

Monday, October 16, 2017

Mounted on metallic asset rfid tag OPP0603 for high temperature


OPP IOT metal tag OPP0603 is specially designed for metallic asset tracking under extremely heat and other harsh environments such as high temperature disinfection,chemical cleaning etc.IP68 waterproof protection makes it survive well in outdoor harsh environment.With up to 90cm reading distance and small size,OPP0603 UHF tags Widely used for asset management in various industrial fields,such as medical devices,surgical instruments tray, heavy industry, oil&gas&mining,automatic production line,logistic tray tracking,warehouse storage rack, container tracking,etc.

Functional Specifications:
RFID Protocol:EPC Class1 Gen2, ISO18000-6C
Frequency:US 902-928MHz, EU 865-868MHz
IC type:Alien Higgs-3
Memory:EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Write Cycles:100,000times
Functionality:Read/write
Data Retention:Up to 50 Years
Applicable Surface:Metal Surfaces
Read Range (On Metal):
(Fix Reader:ThingMagic M6-E, 36dBm/4W) 90cm - (US) 902-928MHz, on metal
80cm - (EU) 865-868MHz, on metal
Read Range(On Metal):
(Handheld Reader: OP9908,R2000,33dBm/2W)
50cm - (US) 902-928MHz, on metal
45cm - (EU) 865-868MHz, on metal
Warranty:1 Year

Physical Specification:
Size:6x3mm
Thickness:4.0mm with IC bump
Material:FR4 (PCB)
Colour:Black (Red, Blue, Green, White)
Weight:0.5g

Enivironmenal Specification:
IP Rating:IP68
Storage Temperature:-40°C to +150°C
Operation Temberture:-40°C to +100°C
Certifications:Reach Approved,RoHS Approved,CE Approved

More view http://www.oppiot.com/uhf-metal-tags-atom-series-opp0603.html

OPP0803 UHF tags is specially designed for harsh industrial applications and temperatures ranging from -40℃ to +150℃.



OPP IOT presents a wide collection of high-temperature RFID tags with different protocols design to provide asset tracking even in the harshest environments.OPP0803 UHF tag is specially designed for harsh industrial applications and temperatures ranging from -40℃ to +150℃.

Functional Specifications: RFID Protocol:EPC Class1 Gen2, ISO18000-6C Frequency:US 902-928MHz, EU 865-868MHz IC type:Alien Higgs-3 Memory:EPC 96bits (Up to 480bits) , USER 512bits, TID64bits Write Cycles:100,000times Functionality:Read/write Data Retention:Up to 50 Years Applicable Surface:Metal Surfaces Read Range (On Metal): (Fix Reader:ThingMagic M6-E, 36dBm/4W) 95cm - (US) 902-928MHz, on metal 90cm - (EU) 865-868MHz, on metal Read Range(On Metal): (Handheld Reader: OP9908,R2000,33dBm/2W) 50cm - (US) 902-928MHz, on metal 45cm - (EU) 865-868MHz, on metal Warranty:1 Year Physical Specification: Size:8x3mm Thickness:3.0mm with IC bump Material:FR4 (PCB) Colour:Black (Red, Blue, Green, White) Weight:0.5g Enivironmenal Specification: IP Rating:IP68 Storage Temperature:-40°C to +150°C Operation Temberture:-40°C to +100°C Certifications:Reach Approved,RoHS Approved,CE Approved

More view http://www.oppiot.com/uhf-metal-tags-atom-series-opp0803.html
